Tympanometers TouchTymp RaceCar

Product Name: Tympanometers – TouchTymp RaceCar

The TouchTymp RaceCar is a next-generation pediatric tympanometer designed to deliver fast, precise, and stress-free middle ear testing for children. Featuring an engaging animated race car interface, it helps keep young patients focused and calm during tympanometry and reflex screening, reducing movement and minimizing the need for repeat tests.

Key Features

• Interactive RaceCar animation designed for child-friendly testing
• Fast, accurate middle ear and tympanometry analysis
• Full touch-screen interface for simple, intuitive operation
• Built-in thermal printer for instant result output
• Customizable test protocols and flexible settings
• High-resolution display with smooth, quick screen transitions
• Reduces probe seal loss and repeat measurements
• Lightweight handheld probe with indicator light and control switch
• USB connectivity for PC integration
• Compact, portable and clinic-friendly design

Technical Specifications

• Probe Frequency: 226 Hz ±1%, 85 dB SPL
• Optional High Frequency: 1000 Hz ±1%, 69 dB SPL
• Pressure Range: -600 to +400 daPa
• Volume Range: 0.0 to 6.0 ml (compensated)
• Compliance Range:
  • 0.1 to 8.0 ml at 226 Hz
  • 0.1 to 15.0 mmho at 1000 Hz (optional)
• Test Time: Approx. 3–5 seconds
• Pressure Accuracy: ±5% or ±10 daPa
• Volume Accuracy: ±5% or 0.1 ml
• Test Frequencies: 500 Hz, 1000 Hz, 2000 Hz, 4000 Hz
• Reflex Testing: Ipsilateral & optional contralateral
• Reflex Intensity Range:
  • Ipsilateral: 70–105 dB HL
  • Contralateral: up to 120 dB HL
• Display: 10.4-inch graphical LED touchscreen
• Power Supply: 100–240V AC
• Built-in fast thermal printer

Applications

• Pediatric hearing screening
• Middle ear function analysis
• Tympanometry testing
• Acoustic reflex testing
• ENT departments and audiology clinics

Benefits

• Improves child cooperation during testing
• Makes hearing assessment more engaging and less stressful
• Reduces testing time for clinicians
• Ensures reliable and consistent diagnostic results
• Ideal for pediatric audiology environments

The TouchTymp RaceCar blends advanced audiology technology with a playful, child-centered design—making pediatric middle ear testing faster, easier, and more comfortable for both clinicians and young patients.
